HSL2 Minority Carrier Lifetime Analyzer

No. HSL2

HSL2 Minority Carrier Lifetime Analyzer

Features
● Conforms to American ASTM standards
● Can measure silicon wafers and silicon blocks, can increase minority carrier lifetime map
● Non-destructive and non-contact measurement
Main parameters
Test range and accuracy
Testable Materials	Monolithic or bulk silicon materials
	Solar cell after diffusion to form PN (without metal electrode)
Minority carrier lifetime test range	1 μs~1000μs
Resistivity test range	≥0.1Ωcm
Resolution	5mm
Test non-repeatability	≤2%
Test speed	5 Seconds/points
Mechanical parameters
Microwave source	Lengthwidthheight: 1400mm1380mm810mm
Industrial Computer
Pulsed laser source
Requirements
powered by	AC single phase, 220V/110V±10%, 20A, 50/60Hz

GET A QUOTE

产品详情
Contact Us

HSL2 Minority Carrier Lifetime Analyzer

Features
● Conforms to American ASTM standards
● Can measure silicon wafers and silicon blocks, can increase minority carrier lifetime map
● Non-destructive and non-contact measurement
Main parameters
Test range and accuracy
Testable Materials	Monolithic or bulk silicon materials
	Solar cell after diffusion to form PN (without metal electrode)
Minority carrier lifetime test range	1 μs~1000μs
Resistivity test range	≥0.1Ωcm
Resolution	5mm
Test non-repeatability	≤2%
Test speed	5 Seconds/points
Mechanical parameters
Microwave source	Lengthwidthheight: 1400mm1380mm810mm
Industrial Computer
Pulsed laser source
Requirements
powered by	AC single phase, 220V/110V±10%, 20A, 50/60Hz
