Features |
|
|
● The test principle adopts the internationally recognized microwave reflection photoconductivity decay method |
|
|
● Use professional lasers with sufficient pulse energy and suitable wavelength as the excitation source, with reliable and stable performance |
|
|
● Convenient and intuitive operation process with simple steps |
|
|
Main parameters |
|
|
Test range and accuracy |
|
|
Testable Materials |
Silicon wafer or bulk silicon material |
|
Solar cell after diffusion to form PN (without metal electrode) |
|
|
Minority carrier lifetime test range |
(1~1000)μs |
|
Resistivity test range |
≥0.1Ω·cm |
|
Test non-repeatability |
≤5%( When the test conditions remain unchanged) |
|
Test speed |
2 Seconds/points |
|
Mechanical parameters |
|
|
Microwave source |
10Kg; 465mm( Length)*230mm(width)*470mm(height) |
|
Industrial Computer |
20Kg; 500mm( Length)*400mm(width)*170mm(height) |
|
Pulsed laser source |
10Kg; 350mm( Length)*130mm(width)*450mm(height) |
|
Requirements |
|
|
powered by |
220VAC±10%, 20A, 50/60Hz , single-phase electricity |
